Series CWSB
Neon Miniature Power Rockers
General Specifications
B
Electrical Capacity (Resistive Load)
Power Level: 9A @ 125V AC
Other Ratings
Contact Resistance:
Insulation Resistance:
Dielectric Strength:
Mechanical Life:
Electrical Life:
Nominal Operating Force:
Angle of Throw:
Materials & Finishes
Rocker:
Housing:
Movable Contactor:
Movable Contacts:
Stationary Contacts:
Switch Terminals:
Lamp Terminals:
Environmental Data
Operating Temp Range:
Humidity:
Vibration:
Shock:
Installation
Soldering Time & Temp:
Standards & Certifications
UL:
CSA:
B18
20 milliohms maximum
500 megohms minimum @ 500V DC
1,500V AC minimum between contacts for 1 minute minimum;
3,000V AC minimum between contacts & case for 1 minute minimum
30,000 operations minimum
10,000 operations minimum
10.0N
30°
Polycarbonate
Polyamide
Beryllium copper with silver plating
Silver alloy
Silver alloy
Brass with silver plating
Brass with silver plating
–20°C through +85°C (–4°F through +185°F)
90 ~ 95% humidity for 96 hours @ 40°C (104°F)
10 ~ 55Hz with peak-to-peak amplitude of 0.75mm traversing the frequency range
& returning in 1 minute; 3 right angled directions for 2 hours
50G (490m/s 2 ) acceleration (tested in 6 right angled directions, with 5 shocks in each direction)
Manual Soldering: See Profile B in Supplement section.
File No. E44145
9A @ 125V AC
Markings on case are standard.
File No. 0701166_0_000
9A @ 125V AC
Markings on case are standard.
www.nkk.com
